Device type Thermal imaging device
Type No. 1970
Order No. 50 502
Scope of delivery Calonox View, cordura case, charging cable,
carry strap, quick start guide, lens cleaning
cloth, certificate
Sensor type VOx
Sensor size 640 x 512 pixels
Pixel size 12 μm
Screen type LCOS
Screen diagonal 0.4”
Screen resolution 1280 x 960 pixels
Image repetition frequency 50 Hz
Lens focal length 42 mm
Optical basic magnification 2.5x
Digital Zoom 1x/2x/3x/4x
Field of view 10.5 x 8.4° (18.3 m x 14.6 m/100 m)
Diopter adjustment ±5 dpt
Range/Resolution (calculated for image subject 1.7 m x 0.5 m (66.9 inch x 20.0 inch))
Detection range/Resolution 3000 m/2 pixels (3281 yrd/2 pixels)
Recognition range/Resolution 1000 m/6 pixels (1094 yrd/6 pixels)
Identification range/Resolution 500 m/12 pixels (547 yrd/12 pixels)
Adjustment reticle correction –
Video output PAL
Video recording yes
Video/Picture resolution 768 x 576 pixels
Cable socket USB-C
Wireless connection Wi-Fi (2.4 GHz)
Internal memory 16 GB
Protection type IP67
Operating temperature -10 to +50 °C (-4°F to 122°F)
Operating temperature (charge battery) +10 to +30 °C (50°F to 86°F)
Battery life approx. 4 – 5 h
Accessory thread –
Tripod thread A ¼ DIN 4503 (¼”), M5 standard thread
Dimensions (WxH) 170 x 65 mm (6.7 x 2.6 inch)
Weight (with battery) 685 g (24.2 oz)
